AFG 3011 / 3021B / 3022B / 3101 / 3102 / 3251 / 3252 Datasheet

Features & Benefits

  1. With 25 MHz or 60MHz bandwidth, 2 output channels, 1 mVpp to 10 Vpp output amplitude across full bandwidth, Tektronix AFG1000 Arbitrary/Function Generator generates all kinds of waveforms needed in a lab. Most importantly, it offers the best value for money in the Tektronix line-up of arbitrary function generators. See more signal generators ».
  2. 2 AFG3000 Series Quick Start User Manual To Generate a Sine Waveform The following quick tutorial describes how to generate a continuous sine waveform using Tektronix AFG3000 Series Arbi-trary/Function Generators. Follow these steps to learn the basics of the arbitrary/function generator. Connect the power cord, and then.

10 MHz, 25 MHz, 100 MHz, or 240 MHz Sine Waveforms

14 bits, 250 MS/s, 1 GS/s, or 2 GS/s Arbitrary Waveforms

Amplitude up to 20 V

p-p

into 50 Ω Loads

5.6 in. Display for Full Confidence in Settings and Waveform Shape

Tektronix AFG3000 Series Arbitrary / Function Generator represents a breakthrough in signal source technology. The large display and intuitive user interface makes this product easy to learn and use. The AFG3000 Arbitrary / Function Generator generates frequencies up to 240 MHz and sampling rates up. Aug 26, 2004  AFG310. AFG320. Arbitrary Function Generators. The AFG300 Series is an excellent 16 MHz function generator with built-in arbitrary waveform, burst, sweep, and modulation capabilities. Waveforms can be downloaded directly from selected Tektronix oscilloscopes and arbitrary waveform generators via GPIB, created with the standard.

Multilanguage and Intuitive Operation Saves Setup Time

Pulse Waveform with Variable Edge Times

AM, FM, PM, FSK, PWM

Sweep and Burst

Dual-channel Models Save Cost and Bench Space

USB Connector on Front Panel for Waveform Storage on Memory
Device

USB, GPIB, and LAN

LabVIEW and LabWindows/IVI-C Drivers

Applications

Electronic Test and Design

Sensor Simulation

Functional Test

Generator

Education and Training

Product Description

Unmatched performance, versatility, intuitive operation, and affordability
make the AFG3000 Series of Function, Arbitrary Waveform, and Pulse
Generators the most useful instruments in the industry.

Superior Performance and Versatility

Users can choose from 12 different standard waveforms. Arbitrary
waveforms can be generated up to 128 K in length at high sampling
rates. On pulse waveforms, leading and trailing edge time can be set
independently. External signals can be connected and added to the output
signal. Dual-channel models can generate two identical or completely
different signals. All instruments feature a highly stable time base with only
±1 ppm drift per year.

Intuitive User Interface Shows More Information at a
Single Glance

A large screen shows all relevant waveform parameters and graphical wave
shape at a single glance. This gives full confidence in the signal settings
and lets you focus on the task at hand. Shortcut keys provide direct access
to frequently used functions and parameters. Others can be selected
conveniently through clearly structured menus. This reduces the time
needed for learning and relearning how to use the instrument. Look and feel
are identical to the world's most popular TDS3000 Oscilloscopes.

ArbExpress™ Software Included for Creating
Waveforms with Ease

With this PC software waveforms can be seamlessly imported from any
Tektronix oscilloscope, or defined by standard functions, equation editor,
and waveform math.
