Summary of the content on the page No. 1
TM
®
Smart-UPS
Models 900,
1250 and 2000
User's User's User's User's User's
Manual Manual Manual Manual Manual
Summary of the content on the page No. 2
Important safety instructions! Please read this manual! Veuillez lire ce manuel! Bitte lesen Sie dieses Anleitungshandbuch! ¡Se ruega leer este manual de instrucciones! This manual provides safety, installation and operating instructions that will help you derive the fullest performance and service life that the UPS has to offer. PLEASE SAVE THIS MANUAL ! It includes important instructions for the safe use of this UPS and for obtaining factory service should the proper operation of the UPS come
Summary of the content on the page No. 3
For UPS installation information, see the Smart-UPS Quick-Start Guide that is included with the UPS. The guide is also available on the enclosed CD and the APC Web site at www.apc.com. Network Management Card For installation information, see the user manual provided with the. Ups is an apc back-ups ns 1250. The software and create windows password reset disk by follow the instructions. Inspired by OS X's Get Info option, Elcometer 345 User Manual for Mac comes APC BACK UPS NS 1250 MANUAL If you want to check out images. A crack is a set of instructions or patch used to remove copy protection from a piece.
Table of contents 1.0 Introduction...................................................................... 2 2.0 Safety! .............................................................................. 4 Sécurité! (Français) ............................................................................................... 5 Sicherheit! (Deutsch) ............................................................................................ 6 ¡Seguridad! (Español) ..........................................
Summary of the content on the page No. 4
1.0 Introduction 1.1 Overview This equipment is a high performance line interactive uninterruptible power source (UPS) designed to provide clean, reliable AC power to computer loads. The UPS's line interactive circuit topology, illustrated below, offers excellent efficiency, on-line voltage regulation and fast utility fault response. The UPS’s DC-to-AC inverter is always connected to the output and when operating on- line, a portion of the inverter circuitry is put to work “in reverse” to conti
Summary of the content on the page No. 5
1.0 Introduction 1.2 SmartBoost SmartBoost allows continuous on-line operation during extended brownouts or low line voltage conditions. The UPS compensates for the reduced line voltage by boosting the load voltage to a value 12% above the input. Reliability is enhanced because the limited battery capacity is saved for complete utility failures. 1.3 Battery replacement indicators and test The UPS provides both visual and audible Replace Battery indications. The indications are based on the re
Summary of the content on the page No. 6
ENGLISH 2.0 Safety ! Caution! CAUTION ! ■ To reduce the risk of electric shock, disconnect the Uninterruptible Power Source from the mains before installing computer interface signal cable (when used). Reconnect the power cord only after all signalling interconnections have been made. ■ Connect the Uninterruptible Power Source to a two-pole, three-wire grounding mains receptacle. The receptacle must be connected to appropriate branch protection (fuse or circuit breaker). Connection to a
Summary of the content on the page No. 7
FRANÇAIS 2.0 Sécurité ! Attention! ATTENTION! ■ Pour réduire le risque d’électrocution, débranchez la prise principale de la source d’alimentation permanente (Uninterruptible Power Source), avant d’installer le câble d’interface allant à l’ordinateur (si utilisé). Ne rebranchez le bloc d’alimentation qu’après avoir effectué toutes les connections. ■ Branchez la source d’alimentation permanente (UPS) dans une prise de courant à 3 dérivations (deux pôles et la terre). Cette prise doit être m
Summary of the content on the page No. 8
DEUTSCH 2.0 Sicherheit ! Vorsicht! VORSICHT! ■ Um die Gefahr eines elektrischen Schlages auf ein Minimum zu reduzieren, die unterbrechungsfreie Stromversorgung vom Stromnetz trennen, bevor ggf. ein Com- puter-Schnittstellensignalkabel angeschlossen wird. Das Netzkabel erst nach Herstellung aller Signalverbindungen wieder einstecken. ■ Die unterbrechungsfreie Stromversorgung an eine geerdete zweipolige Dreiphasen- Netzsteckdose anschließen. Die Steckdose muß mit einem geeigneten Abzweigschut
Summary of the content on the page No. 9
ESPAÑOL 2.0 ¡ Seguridad ! ¡Atencion! ¡ATENCION! ■ Para reducir el riesgo de descarga eléctrica, desconecte de la red la Fuente de energía ininterrumpible antes de instalar el cable de señalización de interfaz de la computadora (si se usa). Vuelva a conectar el conductor flexible de alimentación solamente una vez efectuadas todas las interconexiones de señalización. ■ Conecte la Fuente de energía ininterrumpible a un tomacorriente bipolar y trifilar con neutro de puesta a tierra. El tomacor
Summary of the content on the page No. 10
3.0 Presentation 3.1 900VA and 1250VA models - 100, 120 Vac versions Display On / Test / Front view features Alarm disable See section pushbutton 5.0. See section 5.1. Power standby pushbutton See section 5.1. Site wiring Computer fault light interface See section port 4.6. See section 6.0. Option Circuit switches breaker See section 5.6. UPS IEC 320 enable inlet switch See section 4.4. NEMA 5-15R receptacles Rear view Page 8
Summary of the content on the page No. 11
3.0 Presentation 3.2 900VA and 1250VA models - 220/230/240 Vac version Display On / Test / Front view features Alarm disable See section pushbutton 5.0. See section 5.1. Power standby pushbutton See section 5.1. Computer interface port See section Option 6.0. switches See section Circuit 5.6. breaker IEC 320 inlet UPS enable switch See section IEC 320 4.4. output couplers All couplers are protected by the UPS. Rear view Page 9
Summary of the content on the page No. 12
3.0 Presentation 3.3 2000VA model - 100, 120 Vac versions 15Amp circuit Option UPS enable Site wiring On / Test / Alarm breaker Computer switches switch fault light disable pushbutton protects side interface port See section See section See section See section 5.1. receptacles See section 6.0. 5.6. 4.4. 4.6. Display 15Amp features circuit See breaker section protects 5.0. center Power receptacles standby pushbutton NEMA See section 5-15R 5.1. receptacles Electronics enclosure Battery pack couple
Summary of the content on the page No. 13
3.0 Presentation 3.4 2000VA model - 120 Vac versions options The -1, -2 and -4 wiring device options for the 120 Vac version 2000VA model UPS are shown below for reference. These options allow simple plug-in installation of the UPS where special service or load wiring devices are used. Note: Option -3 has been replaced by an improved standard version - it is no longer offered. Note: Due to the difference in available capacity of the UPS and the maximum usable current ratings of the wiring devic
Summary of the content on the page No. 14
3.0 Presentation 3.5 2000VA model - 208 Vac version and options The standard 208 Vac version 2000VA model UPS and its wiring device options are shown below for reference. These options allow simple plug-in installation of the UPS where special service or load wiring devices are used. Standard Option -1 Option -2 3.5.1 Standard 208 Vac version UPSs have the following wiring devices: (2) NEMA L6-30R twist lock receptacles, (1) NEMA L6-30P twist lock input plug. 3.5.2 Option -1 208 Vac version UPS
Summary of the content on the page No. 15
3.0 Presentation 3.6 2000VA model - 220/230/240 Vac version On / Test / Alarm UPS enable Computer Option 15Amp disable pushbutton switch interface port switches circuit See section 5.1. See section 4.4. See section 6.0. See section 5.6. breaker Display features See IEC 320 section inlet 5.0. Power IEC 320 standby output pushbutton couplers See section All couplers 5.1. are protected by the UPS. Electronics Battery pack enclosure coupler and UPS locking plate Battery See section pack 4.3. Battery
Summary of the content on the page No. 16
4.0 Installation 4.1 Receiving inspection Once the UPS has been removed from its shipping container, it should be inspected for damage that may have occurred while in transit. Immediately notify the carrier and place of purchase if any damage is found. The packing materials are made from recyclable materials and should be saved for reuse or disposed of properly. 4.2 Placement The UPS may be installed in any protected environment. The location should provide adequate air flow around the unit,
Summary of the content on the page No. 17
4.0 Installation 4.3 Connect battery pack - 2000VA model only Follow the instructions listed below to install and lock the battery pack coupler. Note: Use only factory supplied or authorized battery packs! 4.3.1 Use a phillips screwdriver to remove the battery coupler clamp from the electronics enclosure. 4.3.2 Turn the battery coupler clamp and refasten loosely at one side. 4.3.3 Mate the battery pack coupler to the electronics enclosure. 4.3.4 Fasten remaining side of battery coupler clamp to
Summary of the content on the page No. 18
4.0 Installation 4.4 Connect UPS to service and enable - continued ■ 220/230/240 Vac versions The 220/230/240 Vac version UPS is not furnished with an input line cord. Instead, two output cords are supplied. However, in most installations it will not be necessary to purchase a UPS input power cord. Simply swap the line cords from your equipment with the furnished output cords. Plug in the UPS using one of the swapped out 2 equipment cords. The UPS's input cord must be three conductor, each
Summary of the content on the page No. 19
4.0 Installation 4.5 Plug loads into UPS Plug all loads to be protected into the UPS. Do not exceed the UPS's capacity as given in section 9.0. Once switched on, the UPS will monitor and display the magnitude of the applied load. Note: Do not plug laser printers into this UPS. Laser printers draw a considerable amount of power. This will reduce the available backup time and in some cases will cause the UPS to signal an overload. 4.6 Check Site Wiring Fault indicator - 100, 120 Vac versions
Summary of the content on the page No. 20
5.0 Operation 5.1 Display features On Battery On, Test, Alarm SmartBoost Replace indicator disable pushbutton indicator On Line Battery indicator indicator Power Battery bar graph capacity & line Power standby voltage bar pushbutton graph 5.1.1 On / Test / Alarm disable pushbutton The On / Test / Alarm disable pushbutton is used to control activation of the UPS and to energize the load. Once the UPS is energized, pressing the button will initiate a battery test. This will force the UPS to oper
APC Smart-UPS
Uninterruptible Power Supply
120 VAC User’s Manual
990-7016B, Revision 3
Initial Start-Up
To obtain warranty coverage, please fill out and return the
warranty registration card now.
Inspection
Inspect the UPS upon receipt. Notify the carrier and dealer if there
is damage. The packaging is recyclable; save it for reuse or
dispose of it properly.
Placement
Install the UPS in a protected area that is free of excessive dust
and has adequate air flow. Do not operate the UPS where the
temperature and humidity is outside the specified limits.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the warranty.
Installation
To install this UPS, please follow the installation instructions
in the Smart-UPS Quick Reference Guide.
This UPS is equipped with a SmartSlot for accessories. See
the APC Website (www.apcc.com) for available accessories.
Check the Site Wiring Fault Indicator
Caution: If the site wiring fault indicator lights, get a
qualified electrician to correct the building wiring.
Charge the battery
The UPS charges its battery whenever it is connected to utility
power. The battery will charge fully during the first 4 hours of
normal operation. Do not expect full runtime during this initial
charge period.
Apc Back-ups 1250 Manual
Rear Views
2200 and 3000 VA
1000 and 1400 VA
450 and 700 VA
Connect Computer Interface Port (Optional)
Power management software and interface kits can be used with
this UPS. Use only kits supplied or approved by the manufacturer.
If used, connect the interface cable to the 9-pin computer interface
port on the back panel of the UPS. Secure the connector’s screws
to complete the connection.
Connect Ground Leads to TVSS Connector
(Optional)
The UPS features a TVSS connector for connecting the ground
lead on transient voltage surge-suppression (TVSS) devices such
as telephone and network line protectors. The TVSS connector
provides grounding through the UPS’s power cord ground
conductor. To make a connection to the TVSS connector, loosen
the screw and connect the surge suppression device’s ground lead.
Tighten the screw to secure the lead.
Battery Pack Connector (3000 VA only)
Use the battery pack connector to connect the optional
external battery pack.
Voltage Sensitivity
The UPS detects line voltage distortions such as spikes, notches,
dips, and swells, as well as distortions caused by operation with
inexpensive fuel-powered generators. By default, the UPS reacts
to distortions by transferring to on-battery operation to protect the
loads. Where power quality is poor, the UPS may frequently
transfer to on-battery operation. If the loads can operate normally
under such conditions, battery capacity and service life may be
conserved by reducing the sensitivity of the UPS.
To reduce UPS sensitivity, press the configuration button on
the rear panel. Use a pointed object such as a pen to press the
button. Press it once to set the UPS’s sensitivity to reduced. Press
it again to set the sensitivity to low. Press the button a third time
to reset normal sensitivity.
When the UPS is set to normal sensitivity, the
configuration LED is brightly lit. When it is set to
reduced sensitivity, the LED is dimly lit. When it is
set to low sensitivity, the LED is off.
Low Battery Warning Interval
By default, the low battery warning occurs when there are
approximately two minutes of on-battery run time remaining. This
may not be enough time to gracefully shut down some protected
computer systems.
To change the warning interval, press the rear panel
configuration button while pressing and holding the front-panel
on/test button.
Press the configuration button once to set the low
battery warning interval to approximately five
minutes. Press it again to set the interval to
approximately seven minutes. Press the button a
third time to reset the interval to two minutes.
Operating Instructions
Switch On — Switch Off
With the UPS plugged in, press and release the large
upper on/test button to supply power to the loads. The
loads are immediately powered while the UPS performs a
self-test.
Press and release the small, lower off button to turn off power
to the loads. It may be convenient to use the UPS as a master
on/off switch for the protected equipment.
Note: Whenever the UPS is plugged in and utility voltage is
present, the charger maintains battery charge.
The on-lineLED illuminates when the UPS is supplying
utility power to the loads.
Self-test
The UPS performs a self-test automatically when turned on, and
every two weeks thereafter (by default). Automatic self-test eases
maintenance requirements by eliminating the need for periodic
manual self-tests.
During the self-test, the UPS briefly operates the loads on-battery.
If the UPS passes the self-test, it returns to on-line operation.
If the UPS fails the self-test it immediately returns to on-
line operation and lights the replace battery LED.
The loads are not affected by a failed test. Recharge the battery
overnight and perform the self-test again. If the replace battery
LED is still on, replace the battery using the Replacing the
Battery procedure.
SmartTrim
The SmartTrim LED comes on to indicate that the UPS is
compensating for a high voltage.
SmartBoost
The SmartBoost LED comes on to indicate that the UPS is
compensating for a low voltage.
On Battery
During on-battery operation, the on-battery LED illuminates and
the UPS sounds an audible alarm consisting of four beeps every
30 seconds. The alarm stops when the UPS returns to on-line
operation.
Low Battery
When the UPS is operating on-battery and the energy reserve of
the battery runs low, the UPS beeps continuously until the UPS
shuts down from battery exhaustion or returns to on-line
operation.
Battery Charge Bar Graph
The 5-LED display on the right of the front panel
shows the present charge of the UPS’s battery as a
percentage of the battery’s capacity. When all five
LEDs light, the battery is fully charged. The top
LED goes out whenever the battery is not 100%
charged. When the LEDs are flashing, the battery
can supply less than the “low battery warning
interval” time for the load.
Shutdown Mode
If there is no utility power present, a host system connected to the
computer interface port can command the UPS to shut down.
This is normally done to preserve battery capacity after a
controlled shutdown of the protected system. In shutdown mode
the UPS stops supplying power to the load, waiting for the return
of utility power.
Apc Ns 1250 Manual
The UPS scrolls the front panel indicators sequentially in
shutdown mode. If the UPS has shutdown due to a low battery,
the UPS lights the Battery Charge Bar Graph only. When line
power is restored, the UPS returns to on-line operation.
Replace Battery
If the battery fails a self-test, the UPS emits short beeps for one
minute and the replace battery LED illuminates. The UPS
repeats the alarm every five hours. Perform the self-test procedure
to confirm replace battery conditions. The alarm stops when the
battery passes the self-test.
Load Bar Graph
The 5-LED display on the left of the front panel
shows the power drawn from the UPS by the load.
The display indicates the percentage of the UPS’s
rated capacity. For example, if three LEDs are lit, the
load is drawing between 50% and 67% of the UPS’s
capacity. If all five LEDs light, thoroughly test your
complete system to make sure that the UPS will not
become overloaded.
Overload
When loads exceed the UPS’s capacity, the overload LED
illuminates, the UPS emits a sustained tone, and the input circuit
breaker may trip (the resettable center plunger of the circuit
breaker pops out). The alarm remains on until the overload is
removed. Disconnect nonessential load equipment from the UPS
to eliminate the overload. If there is AC power and the circuit
breaker does not trip during overload, the loads are still powered.
If the circuit breaker trips and the UPS attempts to go on-battery,
the output AC will shut down.
Cold Start
When the UPS is off and there is no utility power, it is possible to
cold start the UPS to power the loads from the UPS’s battery.
Note: Cold start is not a normal condition.
·
Press and hold the on/test button until the UPS begins
beeping.
· Release the on/test button during the beeping to start the UPS.
Utility Voltage Bar Graph
This UPS has a diagnostic feature that displays the utility voltage.
With the UPS plugged into the normal utility power, press and
hold the on/test button to see the utility voltage bar graph display.
After approximately four seconds the 5-LED display on the right
of the front panel shows the utility input voltage. Refer to the
figure below for the voltage reading.
The display indicates that the voltage is between the
displayed value from the list and the next higher value.
For example, with three LEDs lit, the input voltage is
between 115 and 123 VAC.
If no LEDs come on and the UPS is plugged into a
working AC power outlet, the line voltage is extremely
low.
If all five LEDs come on, the line voltage is extremely high and
should be checked by an electrician.
Note: The UPS starts a self-test as part of this procedure. The
self-test does not affect the voltage display.
Storage
Storage Conditions
Store the UPS covered and upright in a cool, dry location, with its battery fully charged. Before storing,
charge the UPS for at least 4 hours. Disconnect any cables connected to the computer interface port to
avoid unnecessarily draining the battery.
Extended storage
· At -15 to +30 °C (+5 to +86 °F), charge the UPS’s battery every 6 months.
· At +30 to +45 °C (+86 to +113 °F), charge the UPS’s battery every 3 months.
n orm a l
re d u ced
low
2 m in.
5 m in.
7 m in.
100%
80%
60%
40%
20%
85 %
67 %
50 %
33 %
17 %
132
123
Apc Ns 1250 User Manual
115
107
98
